Trimming an Asymmetrical Sail

Asymmetrical spinnakers are great tools in the quiver of any cruising sailor, find out how to get the most out of your sail from the experts.
cruising spinnaker
The cruising asymmetrical is a perfect tool for cruising sailors, but knowing how to use it right is crucial. Quantum Sails

What makes an asymmetrical spinnaker different from a standard spinnaker?

First, geometry: an asymmetrical has a distinct luff and leech. The tack is always the tack, and both sheets are tied onto the same corner (the clew), just like a genoa. Second, the cross-sectional shaping is not uniform and semi-circular – as it would be with a spinnaker – but asymmetrical. The position of maximum camber (draft) is likely to be forward of 50 percent. An asymmetrical typically has a rounder entry (luff) and flatter exit (leech). In general, they are better reaching sails than conventional symmetrical spinnakers, though they can be designed for sailing at broad angles.

At what wind angles can an asymmetrical be carried?

This is a function of design, materials, construction, and, ultimately, of breeze velocity. The flatter and more genoa-like (asymmetrical) the sail, the closer to the wind it can be carried. More spinnaker-like (symmetrical) shapes are larger, fuller sails, optimized for broad reaching and running.

The trick is to strike the right balance for the intended usage, or to have several asymmetricals for different purposes. The lighter the air, the closer to the wind you will be able to sail, regardless of the design. Angles as close as 50 degrees apparent are not uncommon in less than 9-10 knots of wind. The problem for most asymmetricals, particularly on conventional displacement monohulls, comes in 10-14 knots of breeze when trying to sail at broader angles (more than 135 degrees apparent). At these angles and velocities, the sail has trouble being blanketed by the mainsail.

Advertisement

An Asymmetrical Defined

Modern asymmetricals tacked to the stem are designed to rotate area to weather of the centerline. In this range, it pays to have a spinnaker pole and the ability to pull the tack to weather out from behind the mainsail. Like all spinnakers, asymmetricals stay full and pressurized at broader angles in more wind.

What equipment do I need?

• Spinnaker halyard that is above the forestay.

• Tackline led through a block mounted forward of the headstay and aft to convenient cleat.

Advertisement

• Two sheets (approximately twice the length of the boat) led aft to blocks just forward of the stern pulpit.

If racing, or simply optimizing performance at broad angles, a spinnaker pole and after guy can be used to control the tack of the sail and allow it to be pulled aft at broader angles (as with a conventional spinnaker). If a pole is used, you’ll need a tack downhaul (or bobstay).

Rigging an Asymmetrical

• Set on a broad reach where the mainsail will blanket the sail.

Advertisement

• Secure bag near the middle of the foredeck.

• Attach both sheets to the clew, leading the lazy sheet around in front of the headstay.

• Attach downhaul. If there is a bowsprit, lead the downhaul over the sheets (inside jibes). If there’s not a bowsprit, lead the downhaul under sheets (outside jibes).

Advertisement

• Attach halyard, making sure halyard is outside and in front of the headstay.

• Pre-pull the downhaul so that the tack is 3-4 inches off the deck. Pre-pull the clew to the shrouds.

• Hoist rapidly.

• When the sail is fully hoisted, trim the sheet.

A spinnaker sock may be used to keep the sail from filling while you hoist. If using a sock, secure the sock control lines to the mast after hoisting.

Setting

Ease the sheet out until the sail luffs (curls) along the leading edge. Trim in just enough to stop luffing. A periodic curl is good; this indicates the sail is just on the edge of luff. As with all sails, over-trimming is the most common problem. When in doubt, let it out.

For reaching, tighten the downhaul and lower the tack to pulpit-height to minimize luff sag. This will pull the camber (draft) forward, and open the leech. The tighter the downhaul, the more genoa-like the shape will be.

In lighter winds, you can use most asymmetricals as close as 50 degrees apparent wind angle. For running and broad reaching, ease the downhaul and allow the tack to float up 4-6 inches off the deck. This will allow the sail to lift up and the luff to rotate out to weather, away from the blanketing effect of the mainsail. It will also create a more spinnaker-like (symmetrical) shape.

If using a spinnaker pole to control the tack, set the pole just above the pulpit for close reaching. Gradually bring the pole aft, keeping it perpendicular to the apparent wind angle (as with asymmetrical sails). Gradually raise it to keep the tack level with the clew.

Twing Setup

Another useful technique at broader angles is to twing, or move the sheet lead forward. This keeps the clew from rising up and dumping off the leech, making the sail more symmetrical and powerful.

The depth (broad) of the angle you can sail is largely a function of breeze velocity. The lighter the air, the higher the angle (closer to the wind) you will need to sail to keep the asymmetrical full and pulling. You’ll be able to sail lower angles in the puffs, but will have to head up in the lulls.

To find the optimum angle for a given breeze, start with your sail full and pulling. Bear off slowly until the clew begins to droop and the sheet begins to lose pressure, then head back up until the sail is solid and fully pressurized (this magic edge changes with velocity).

Jibes

Asymmetrical spinnakers are jibed, not tacked. To jibe, start with a fully-loaded sail. Bear off slowly, easing the sheet as smoothly and quickly as you can without collapsing the sail. The trick is to use the sheet pressure to get the sail out in front of the boat. If the sail is not eased out before the boat gets downwind, it will collapse and fall into the headstay. As the boat passes through dead downwind, release the old sheet completely and take up the new sheet.

The sail is jibed outside and in front of the headstay when the tack is set on the stem. If you have a long enough bowsprit, you can jibe inside the tack downhaul. No matter which system you use, turn slowly and smoothly from a broad reach to a broad reach. Don’t stop in the middle of the turn, or you’ll encourage the sail to wrap around the headstay.

Watch the sail and turn no faster than the sail can be eased out. Make sure the clew has reached the headstay and is pulled around to the new side before completing the turn. The lighter the air, the higher the reaching angle, both at the outset and as you exit the jibe. In very light air, you may have to physically help the sail around the headstay.

Take Downs

  1. Bear off to a broad reach (10-20 degrees up from a dead-run is best).

  2. Grab the lazy sheet in front of the main boom.

  3. Release the downhaul, or the active sheet, completely, and gather the sail behind the mainsail using the lazy sheet.

  4. Ease the halyard as fast as the sail can be gathered.

  5. Stuff the sail down the companionway or forward hatch as you gather. A spinnaker sock can be pulled over the sail to keep it from blowing out of control. Release the sheet and pull the sock down, then gather. It’s easier to put the sail in a bag later.

Racing take-downs can be done in two other variations. In a weather take-down, the lazy or a special take-down line is led around the headstay. The sheet is released, and the sail is pulled around the headstay to weather and be gathered.

The other option is the envelope drop (this works with loose-footed mainsails only). For this take-down, the lazy sheet is brought completely around to the leeward side and led through the foot of the mainsail. Release the tack completely; gather the sail through the foot of the mainsail and down the main companionway hatch. This type of takedown is particularly effective in windy situations on bigger boats.
